Leica Geovid R 8x56
With the new generation of Geovid R rangefinder binoculars, Leica once again sets new standards. Completely redesigned and technically updated, the new Geovid R models are impressive in every detail. Leica remains true to its brand promise and its focus on the essentials – and continues to evolve as a pioneer with 30 years of experience in rangefinding.
You don’t want to choose between powerful binocular optics and a precise rangefinder? You don’t have to: Geovid R offers the best possible combination in one product, at an attractive price. The extremely compact, lightweight premium binoculars deliver a field of view that is outstanding in their class, as well as great image detail and fascinating color accuracy.
With an improved measurement range of up to 1,800 meters/2.000 yards, you are perfectly equipped for almost any observation and measurement in nature. The newly developed Geovid R models focus fully on Leica’s core values: powerful premium optics, precise rangefinding, maximum optomechanical reliability, and easy, intuitive operation. Thanks to highly efficient manufacturing and a focus on the essentials, you no longer have to choose between conventional binoculars and a rangefinder.
The Essentials:
- Best-in-class optical performance
- Absolutely precise laser rangefinding
- Improved measurement range: up to 2,000 yds (1,800 m)
- New, up-to-date, ergonomic design
- Particularly light, compact construction
| General | |
|---|---|
| Designation | Leica Geovid R 8x56 |
| Device type | Rangefinder |
| Order no. | 40 813 (black) |
| Scope of delivery | Contoured neoprene carrying strap, front lens cover, eyepiece caps, cordura case, battery |
| Optical system | |
| Magnification | 8x |
| Front lens diameter | 56 mm |
| Exit pupil | 7.0 mm |
| Twilight factor | 21.2 |
| Field of view at 1,000 yds / 1,000 m | 354 ft / 118 m |
| Field of view for spectacle wearers | 318.6 ft / 106.2 m |
| Eye relief | 18 mm |
| Objective angle of view | 6.8° |
| Close distance | approx. 18.4 ft / 5.6 m |
| Adjustable interpupillary distance | 58 to 74 mm |
| Diopter compensation | ±4 dpt. |
| Eyepiece for eyeglass wearers | yes |
| Eyecups | yes, rotary sliding sleeve, detachable, with 4 click-stops |
| Prism system | Modified Uppendahl system |
| Lens coating | HDC® multilayer coating |
| Focusing | Internal focusing via central drive |
| Distance measurement | |
| Range | 10 up to approx. 2,000 yds / 1,800 m |
| Equivalent horizontal range (EHR) | 10 up to approx. 1,200 yds / 1,100 m |
| Measuring accuracy | ±1 yd to 383 yds / ±1 m to 350 m ±2 yds to 765 yds / ±2 m to 700 m ±0.5% above 765 yds / ±0.5% above 700 m |
| Measuring time | max. 0.3 sec. |
| Measuring modes | Scan mode, single measurement |
| Switchover meter/yards | yes |
| Ballistic function | no |
| On-board wind correction | no |
| Output “Equivalent horizontal range” | yes |
| Display | LED display with 4 digits, automatic brightness control |
| Laser and sensors | |
| Laser | Eye-safe invisible laser according to EN and FDA class 1 |
| Laser beam divergence | 2.5 × 0.5 mrad |
| Inclination sensor | yes |
| Power and construction | |
| Battery | 1 × 3 V / Lithium-type CR2 |
| Battery lifetime | approx. 2,000 measurements at 68°F / 20°C |
| Watertightness | to a depth of 16.5 ft / 5 m |
| Housing | Aluminum, nitrogen-filled |
| Dimensions (W × H × D) | 5.3 × 7.2 × 2.7 in / 135 × 182 × 68 mm |
| Weight | approx. 38.8 oz / 1,090 g (without battery) |
| Accessories | |
| Winged eyecups | 42 006 |
| Floating carrying strap | 42 163 |
| Tripod adapter | 42 220 |
